EnviroProbe

EnviroProbe monitors temperature, humidity in a single cabinet or area and transmits signals from environment sensor devices in the data center (e.g.: door sensors, smoke detectors, fire detectors, water-leakage detectors and others) to management via network. EnviroProbe also controls its connected devices when equipped with digital and analog outputs, keeping the IT manager promptly informed of all environmental changes by giving alarms, controlling the activation and deactivation of an external device (e.g. a magnetic lock), or by giving a sound alert using its own built-in buzzer upon detection of water leakage.

▲ Connecting EnviroProbes with EnviroStation can expand the scope of the monitored area.

Product available regions :
Because product specifications vary slightly from region to region, please download your local leaflet or visit your local website for detailed product information.

EMEA	North America	South America	SEA	India	China	Taiwan	South Korea
●	●	●	●	●	●	●	●

Request a Quote Subscribe Newsletter

Product Introduction

Related Information

Product Introduction
Related Information
Contact Us

Product Introduction

Features & Benefits

Easy to manage

Monitors temperature and humidity of the environment

Backlight LCD display

Digital/analog inputs and outputs

Convenience

Works with EnviroStation (EMS2000) to monitor via internet browser

InfraSuite Manager software for remote monitoring and recording

Flexibility

Works with EnviroStation (EMS2000) to support SNMP communication protocol

Specifications

Model
EMS1000 / EMS1100 / EMS1200
Input Voltage
EMS2000 Delta-BUS or SNMP Card: 12 Vdc (pin 1 & 4)
PDU SNMP Card: 5 Vdc (Pin 2 & 4)
Purpose
EMS1000: To collect data from connected devices (temperature & humidity)
EMS1100: To control connected devices
EMS1200: To collect data from and control connected devices
Input/Output Contacts
EMS1000:
4 dry/wet contact inputs
Connect to EnviroStation(EMS2000) or SNMP IPv6 card
EMS1100:
4 digital outputs
Connect to EnviroStation(EMS2000) or SNMP IPv6 card
EMS1200:
2 analog inputs, 1 analog output, 1 water-leakage detection (builtin buzzer)
Connect to EnviroStation (EMS2000)
Input
EMS1000:
Wet Contacts:5~24 Vdc, 1~8 mA
Dry Contacts: Open/Short Status
EMS1100: N/A
EMS1200:
Voltage: 0~10 Vdc (12 bit)
Current: 0~20 mA (12 bit)
Output
EMS1000: N/A
EMS1100
Contact voltage / Contact current / Contact tolerance
60 Vdc / 1 A / 60 W
30 Vac / 2.08 A / 62.5 VA
EMS1200
Voltage: 0~10 Vdc (12 bit)
Current: 4~20 mA (12 bit)
Cascade number to EMS2000
EMS1000: Up to 16 units
EMS1100: Up to 4 units
EMS1200: Up to 5 units
Dimensions (W x D x H)
Product: 66 x 33 x 103 mm
Package: 91 x 42 x 133 mm
Weight
EMS1000
Net Weight: 120 g, Gross Weight: 140 g
EMS1100 / EMS1200
Net Weight: 130 g, Gross Weight: 150 g
Environment - Temperature
Operation: 0~60°C
Storage
EMS1000: -20~60°C
EMS1100 / EMS1200: 0~60°C
Accuracy
EMS1000: ± 0.4°C & 0~60°C
EMS1100 / EMS1200: N/A
Environment - Humidity
Operation: 0~90% RH (no condensation)
Storage: 0~100% RH (no condensation)
Accuracy
EMS1000: ± 3°C & 0~80°C
EMS1100 / EMS1200: N/A
Environment - Altitude
EMS1000 / EMS1100 / EMS1200: 0~10,000 feet
Conformance
CE
EN55022 (CISPR 22) Class B
EN55024 (Level 3 @Air 8 KV / contact 4 KV)
These specifications are subject to change without notice. Please contact us or our distributors in your region for the latest specs.
