DPS Series 300-1200 kVA

Features & Benefits

Ultimate Availability

• Supports up to 10 MW power capacity with the parallel redundancy and expansion up to 8 units

• Redundancy components and dual CAN bus ensures system availability

• Proactive detection of key component status for early diagnosis on UPS malfunction

• Intelligent battery health diagnosis enables better battery maintenance and replacement

• Advanced event analysis, including 10,000 event logs, waveform capturing and key paremeters recording, to detect UPS abnomality and ensure higher availability

Excellent Performance

• The industry's leading power density and smallest footprint with the design of both top/bottom cable entry and inbuilt switches, which allows you to flexibly utilize the space under the circumstance of high power requirements

• Unity output power factor guarantees no-rating and provides 100% kW

• AC-AC efficiency of up to 96.5% and 99% in ECO mode resulting in marked energy cost savings

• Supports both VRLA and environment-friendly Li-ion batteries

Sophisticated Manageability and Flexibility

• User-friendly 10” color touch panel simplifies local UPS management

• Environment information, such as security, water, fire, and temperature can be integrated and monitored via the LCD panel of the UPS

• If the UPS is equipped with an external battery management system, the battery information can be integrated and monitored via the LCD panel of the UPS

• Fully front access and modular design of key components shortens the mean time to repair (MTTR)

• Flexible battery quantity of 30-46 pcs achieves optimal battery investment

Applications

Specifications

1. Model
2. DPS-300K / DPS-400K / DPS-500K / DPS-600K
   DPS-800K / DPS-1000K / DPS-1200K

3. ---

4. Power Rating
5. DPS-300K: 300 kVA / 300 kW
   DPS-400K: 400 kVA / 400 kW
   DPS-500K: 500 kVA / 500 kW
   DPS-600K: 600 kVA / 600 kW
   DPS-800K: 800 kVA / 800 kW
   DPS-1000K: 1000 kVA / 1000 kW
   DPS-1200K: 1200 kVA / 1200 kW

6. ---

7. Input
8. Nominal Voltage: 220/380 Vac, 230/400 Vac, 240/415 Vac (3-phase, 4-wire + G)
9. Voltage Range: 176/304~276/478 Vac (full load)
10. Current Harmonic Distortion: < 3% (with Full Linear Load); < 5% (with Full Non-linear Load)
11. Power Factor: > 0.99
12. Frequency Range: 40~70 Hz

13. ---

14. Output
15. Voltage: 220/380 Vac, 230/400 Vac, 240/415 Vac (3-phase, 4-wire + G)
16. Voltage Harmonic Distortion: < 1.5% (Linear Load); < 5% (Non-linear Load)
17. Voltage Regulation: ± 1% (static); ± 5% (dynamic)
18. Output Power Factor: 1
19. Frequency: 50/60 Hz (Auto-Selectable)
20. Overload Capability: ≤ 125%: 10 min; ≤ 150%: 1 min; > 150%: 1 sec

21. ---

22. Display : 10” Color Touch Panel

23. ---

24. Interface
25. Standard: RS232, Parallel port, USB, Modbus RS485, Input dry contact, Output dry contact, SNMP card inbuilt in touch screen
26. Optional: Relay I/O card, Battery cabinet temperature sensor cable

27. ---

28. Conformance
29. Safety: CE

30. ---

31. Efficiency
32. AC-AC: Up to 96.5%
33. ECO Mode: 99%

34. ---

35. Battery
36. Type: VRLA, LiB
37. Charge Current
    DPS-300K: 90 A
    DPS-400K: 120 A
    DPS-500K: 150 A
    DPS-600K: 180 A
    DPS-800K: 240 A
    DPS-1000K: 300 A
    DPS-1200K: 360 A
38. Battery Quantity: 30~46 pcs

39. ---

40. Environment
41. Operating Temperature: 0~40℃
42. Relative Humidity: 0~95% (non-condensing)
43. Audible Noise: < 80 dB
44. IP Protection: IP20

45. ---

46. Others
47. Parallel Redundancy and Expansion: Maximum 8 units
48. Emergency Power Off: Remote and local

49. ---

50. Physical
51. Dimensions (W x D x H)
    DPS-300K: 600* x 900 x 2000 mm
    DPS-400K/500K/600K: 1200* x 900 x 2000 mm
    DPS-800K: 1800 x 900 x 2000 mm
    DPS-1000K/1200K: 2450 x 900 x 2000 mm
52. Weight
    DPS-300K: 515 kg
    DPS-400K: 700 kg
    DPS-500K: 811 kg
    DPS-600K: 970 kg
    DPS-800K: 1270 kg
    DPS-1000K: 1850 kg
    DPS-1200K: 2000 kg

53. ---

54. * The width is for the cabinet which has four inbuilt switches.
    * For DPS-300K, only top cable entry is available.

    All specifications are subject to change without prior notice.
